Reach Loud and Clear
DJI's First Speaker for Multi-Payload Drone Platforms
When used with Matrice 400, Zenmuse V1 supports real-time broadcasting via the DJI Pilot 2 app, ensuring timely delivery of audio messages. It also features an integrated anti-howling algorithm to optimize clarity during broadcasts.
Record and transmit messages to the speaker using the DJI Pilot 2 app. This feature includes local playback and recording storage. Recording a broadcast is instant and convenient, enabling rapid communication of important information in emergent scenarios without complex operations.
Input text can be converted to speech via the DJI Pilot 2 app and transmitted to the speaker. This mode supports adjustments to tone and speech rate, as well as loop playback, ensuring that information is conveyed clearly and flexibly to the target audience.
The DJI Pilot 2 app supports the import of local audio files, which can then be transmitted to the speaker for playback. When paired with Matrice 400, Zenmuse V1 supports simultaneous file transfer and playback. These allow for the quick dissemination of preset content during operations, enhancing efficiency and smoothness.
At 1 meter, Zenmuse V1's maximum loudness can reach 129 decibels [1], on par with the sound level of a jet taking off. Powerful volume ensures clear communication. With an effective broadcast distance of up to 700 meters, [1] it ensures coverage even in vast areas.
During recording, DJI RC Plus can directionally capture voices directly above the microphone. Combined with environmental noise cancelling technology, it effectively minimizes surrounding noise interference, ensuring clearer recordings.
Zenmuse V1 can synchronize with other gimbal-equipped payloads to achieve coordinated tilt angles, ensuring that the sound is directed precisely towards the intended direction, thereby enhancing the broadcast efficiency. The camera view can display the direction in which the speaker is pointing, making it easy to quickly adjust the sound direction and efficiently broadcast messages to a designated location.
Zenmuse V1 is equipped with multiple protection mechanisms for temperature, overcurrent, power, and more, enhancing the product's reliability and lifespan.
With an IP54 rating for dust and water resistance,[2] Zenmuse V1 can operate in ambient temperatures ranging from -20° to 50° C (-4° to 122° F), making it adaptable to various operating environments.
When used with Matrice 400 and the Zenmuse H30 Series, Zenmuse V1 supports remote, real-time video viewing and speaker control through DJI FlightHub 2.
When paired with Matrice 400, Zenmuse V1 automatically adjusts the volume of live recordings and audio files. This maintains a consistent audio level and enhances the overall user experience.
Zenmuse S1 can be mounted on any gimbal connector of Matrice 400, Matrice 350 RTK, or Matrice 300 RTK, accommodating various operational needs. Weighing only 0.76 kg, [9] it is compact and portable, and it also fits into the carrying case of Matrice 400.
